6 SPECIFICATIONS
6 SPECIFICATIONS
T68/TX·D7
Electrical Specifications
CRT 50 cm (19 inch) class, 90° deflection Aperture Grille type
CRT with Anti-Reflective SuperErgoCoat
®
CRT AG Pitch 0.25 mm (center), 0.27 mm (edges)
Scan Frequency
Horizontal: 30 kHz-96 kHz (Automatic)
Vertical: 50 Hz-160 Hz (Automatic)
Max. Active Display Area 362 mm (H) × 271 mm (V) (14.2” (Η) × 10.7” (V))
(Viewable image siz: 452 mm (17.7”))
* Display size can be set by the user through
microprocessor control panel.
* The actual size displayed can be dependent on the
graphics board or PC utilized.
Power Supply 100-120/220-240 VAC±10%, 50/60 Hz, 1.6/0.8 A
Power Consumption
Normal/Max: 120 W/155 W (with EIZO optional speaker & USB attached)
PowerManager Mode 1: Less than 10 W *
PowerManager Mode 2: Less than 3 W * (* When the USB hub is not connected)
Input Connector D-Sub mini 15-pin and BNC × 5 (switchable)
Recommended Resolution 1280 dots × 1024 lines
Input Signal
Sync: • H/V Separate, TTL, Positive/Negative
• H/V Composite, TTL, Positive/Negative
• Sync on Green 0.3 Vp-p, Negative
Video: • Analog 0.7 Vp-p/75 Ω, Positive
Mechanical Specifications
Dimensions 452 mm (W) × 455 mm (H) × 478 mm (D)
(17.8” (W) × 17.9” (H) × 18.8” (D))
Weight 26.5 kg (58.4 lbs.)
USB Specifications
USB standard Rev. 1.0 complied self-powered hub
Downstream power supply 500 mA for each (Max.)
Communication speed 12 Mbps (full), 1.5 Mbps (low)
USB ports Upstream port x 1, Downstream ports x 4
Environmental Specifications
Temperature operating: 0°C to 40°C (32 °F to 104 °F)
storage: -20°C to 60°C (-20 °F to 140 °F)
Humidity 30% to 80% R.H. Non-condensing
Certifications and Standards
100-120 VAC range UL/CSA, FCC-B, DHHS, TÜV Rheinland/Ergonomics
Approved, TCO’99, EPA Energy Star
®
Program
220-240 VAC range CE, CB, TÜV Rheinland/GS, TÜV Rheinland/Ergonomics
Approved, TCO’99, EPA Energy Star
®
Program
