Chapter 1 Overview and Features
1-3 Basic operation of Adjustment menu and the icon list
Basic operation of Adjustment menu
Displaying the adjustment menu
Pressing the function button to change the setting or pressing allows you to display the adjustment menu.
When pressing the input signal selection, mode, brightness control, or volume control button
When pressing the menu button
Modifying the setting
The operation methods differ depending on the icons.
Example Operation method
As for the icons displayed with the +/- marks, selecting + allows you to increase the setting value
or selecting - to decrease it.
Selecting the icon displayed with mark allows you to show the next menu.
/
The Enable/Disable setting is toggled by selecting the icon.
5
is displayed when the function is
invalid.
Displaying the function name
(1) Press while the adjustment menu appears.
(2) The function name appears.
Storing the setting/Exiting the adjustment menu
After completing the setting, selecting allows you to store the setting. Selecting repeatedly allows you to close
the adjustment menu.
NOTE
• Theadjustmentmenuautomaticallynisheswhennoinputoperationoccursin45seconds.

Eizo FlexScan S1932 Specifications

General

Pixel pitch	0.294 x 0.294 mm
Response time	8 ms
Display diagonal	19 \
Display resolution	1280 x 1024 pixels
Digital vertical frequency	59 - 61 Hz
Digital horizontal frequency	31 - 64 kHz
Display brightness (typical)	250 cd/m²
HDCP	Yes
DVI-I ports quantity	-
USB Type-A downstream ports quantity	0
Power consumption (typical)	45 W
Product color	Gray

Weight and Dimensions

Depth (with stand)	205 mm
Height (with stand)	506 mm
Weight (with stand)	7200 g
Depth (without stand)	62 mm
Width (without stand)	405 mm
Height (without stand)	334 mm
Weight (without stand)	5200 g
