Eizo FORIS FS2434 User Manual

25
Chapter 2 Adjusting Screens
●
HDMI Input (video signal)
The screen size can be changed with the “Screen Size” function.
Setting Function Screen Display
Auto The monitor automatically changes the screen
size according to the aspect ratio
*1
and resolution
information from the external device. This can be set
only for HDMI (SD Signal) input.
Full Screen Displays an image in full screen. Images are
distorted in some cases because the vertical rate is
not equal to the horizontal rate.
Enlarged Displays an image in full screen. In some cases,
a blank horizontal or vertical border appears to
equalize the vertical rate and the horizontal rate.
Letterbox Displays Letterbox of 16 : 9 in full screen. Except for
Letterbox, the upper and lower parts of the projected
image are cut. This can be set only for HDMI (SD
Signal) input.
Normal
*2
The image is displayed without scaling the input
signals.
*1 The aspect ratio information of letterbox cannot be identied automatically.
*2 When “Screen Size” is “Normal”, “Overscan” is xed at “Off”.
Procedure
1. Press
on the remote control.
Each time you press , the size changes.
Attention
• Selecting “Normal” may make some color gradations unavailable for display.
Note
• When “Normal” is selected, the display input lag is 2 frames or less.
To set the screen ratio
In order to hide distortion or noise at the image’s edge, the display area of the input image can be
changed so that peripheral images are not displayed.
Setting Function
On Displays an input image in the screen by trimming the vertical and horizontal parts of the
image.
Off Displays most of the input image.
Procedure
1. Press
on the remote control.
The “Screen Size” menu appears.
2. Select “Overscan” with .
3. Use
or for adjustment.
4. Press
to exit.
Attention
• When “Screen Size” is “Normal”, “Overscan” is xed at “Off”.
