6-1. Connecting Multiple External Devices
The product has multiple connections to external devices and allows you to switch to one of the
connections for display.
Attention
• Do not use dual link cables.
Connection examples
*1 Use a product able to handle High Speed.
HDMI connector DVI-D connector
Digital
(HDMI)
Digital
(DVI)
Signal cable
(supplied FD-C39)
HDMI cable
*1
(Commercially available product)
or
DVI-HDMI converter cable
(Commercially available product)
DVI connector
To ext. device 1
To ext. device 2, 3
HDMI
connector
DVI connector
●
To switch among input signals
Press or on the remote control to change the input signal.
When the signal is switched, the active input port name appears at the top right corner of the screen.
Note
• on the monitor also can change the input (see “1-2. Controls and Functions” (page 8)).
