Troubleshooting with software
27
EXPLANATION
Use this command to display the current state of mastership.
5.6.2 CHECK_LINE
SYNTAX
CHECK_LINE [a/b]
a = line A
b = line B
EXPLANATION
Verifies the operation of the line defined by the parameters a or b. If no parameter is
given, line A is tested. The command sends ff frames to each line and tells you how
many were erroneous.
When you transmit data to the lines with this command, you can also measure the line
voltages and signal shapes using an oscilloscope.
EXAMPLE
bg>check_line a
Testing line A:
-----------------
- frames sent: FF
- errors: 00
dbg>check_line b
Testing line B:
-----------------
- frames sent: FF
- errors: 00
5.6.3 CTRL (D)
This command alters the functionality of the Multifunction Vehicle
Bus. Consider the operative situation carefully before using this
command on board a train.
SYNTAX
CTRL dev16 t8 cmd8
dev16 = device address
t8 = value of t_ignore
