Troubleshooting with software
39
If you give the ADDR command with no parameter, it displays the current
addressing mode.
Please note that all parameters must be entered in lower case.
5.7.2 MEM - Memory switch
SYNTAX
MEM [s|t|f]
s = shared memory
t = traffic memory
f = flash memory
EXPLANATION
The memory visible at absolute (physical) address space C0000h can be selected or
shown with this command. The possibilities are Shared Memory, Traffic Memory and
FLASH Memory.
EXAMPLE
To make FLASH memory visible, type:
mem f
The following text is displayed:
Flash currently visible at c0000h.
5.7.3 RM - Read Memory
SYNTAX
RM addr32 count8
0xB000 - 0xCFFF 8 KB window for accessing
the Shared Memory, Traffic
Memory, constant strings
and banked code of the
module.
Depends on the value of the
BBR register.
0xD000 - 0xFFFF Firmware data area Overlaps the area in physical
address space starting at
0x10000.
Address range in logical
addressing mode
Memory contents Address in absolute
addressing mode
