Troubleshooting with software
46
Device address 0100
Logical ports:
Handle Desc Addr Size (words)F-code BP
-------------------------------------------------------------------
00 Source 0100h 01h 00 00h
01 Source 0101h 01h 00 01h
02 Source 0102h 01h 00 02h
03 Source 0103h 01h 00 03h
04 Source 0104h 01h 00 04h
05 Source 0105h 01h 00 05h
06 Source 0106h 01h 00 06h
07 Source 0107h 01h 00 07h
08 Sink 0108h 01h 00 08h
09 Sink 0109h 01h 00 09h
0A Sink 010Ah 01h 00 0Ah
0B Sink 010Bh 01h 00 0Bh
0C Sink 010Ch 01h 00 0Ch
0D Sink 010Dh 01h 00 0Dh
0E Sink 010Eh 01h 00 0Eh
0F Sink 010Fh 01h 00 0Fh
dbg>
5.8.5 LOS - List of Slaves
SYNTAX
LOS
EXPLANATION
Use this command to display the list of the logical ports of all the slaves.
This command is only applicable in the Debug Mode. See
MVB_MODE (page 44).
5.8.6 LPORT - Modify the logical port of an active slave
SYNTAX
LPORT handle8 o/i addr16 size8 bp8
EXPLANATION
After creating a slave with the command CS (or AS), use this command to modify a
logical port specified by a handle. You can change all of the preconfigured parameters:
type (source/sink), logical address, size and basic period. Source is identified with the
letter ’o’ and sink with the letter ’i’. The letters ’o’ and ’i’ MUST be in lower case. Size
(in words) must be entered in hex format. So, the possible values are 1, 2, 4, 8 and 10h.
