Troubleshooting with software
45
EXPLANATION
Use this command to see or to set the current MVB access mode. Mode must be set
to Debug Mode if slaves are to be configured through a debug terminal. The default
mode is Normal Mode, meaning that terminal configurations are prevented.
In the Debug Mode the module no longer receives data from the VME bus.
5.8.4 LOP - List of ports
SYNTAX
LOP
EXPLANATION
In normal mode
Use this command to display the list of the logical ports of the active slave.
EXAMPLE, normal mode
The output is like the following.
dbg>lop
Basic_Period: 03E8h us
Macro_Cycle: 0400h ms
Event_Poll_Strategy: C000h
Macro_Cycles_Per_Turn: 0005h
Process_Data Ports:
Address F-code Type Polls in Macro
----------------------------------------------
0001h 01 sink 0400h
0002h 02 source 0200h
0004h 04 sink 0100h
0008h 04 source 0080h
0016h 01 sink 0040h
0024h 02 sink 0001h
0032h 03 source 0020h
0064h 00 sink 0010h
0128h 01 source 0008h
0256h 03 sink 0004h
0512h 01 source 0002h
EXAMPLE, debug mode
The output is like the following.
dbg>lop
