58
Block diagram
The following pictures shows the MVB block diagram.
Figure B.1: MVB block diagram
MVBC01
(MVBC02C)
ASIC
VME
Interface
Software
Traffic
Memory
FPGA
ESD
EMD
M1
male
M2
female
A.DATA_P
A.DATA_N
B.DATA_P
B.DATA_N
Terminators
Terminators
