Installation
EKEVO 6/EKEVO 7/EKEVO 8/EKEVO 9
Air duct connection
Rotating air box
EKEVO 6/EKEVO 7
EKEVO 8/EKEVO 9
for dimensions: see technical data
EKEVO 6/EKEVO 7
for dimensions: see technical data
EKEVO 8/EKEVO 9
* Rotation procedure of air box: see chapter
«Servicing»
