11 TECHNICAL SPECIFICATION
Range: 0 µm to 1500 µm (0 mil to 60 mil)
Accuracy: ± 3% of the reading or ± 2.5 µm (0.1 mil)
whichever is the greater.
± 1% of the reading or ± 2.5 µm (0.1 mil)
whichever is the greater when calibrated close to the thickness to be
measured.
Resolution, metric: 1 µm
Below 20 µm, 0.1 µm
Resolution, imperial: 0.1 mil
Below 1 mil, 0.01 mil
Display: Liquid Crystal Display (LCD) 3½ Digits, Character height: 10 mm (0.4")
Operating Temperature: 0°C to 50°C (32°F to 120°F)
Dimensions: 56 mm x 24 mm x 120 mm (2.2" x 0.95" x 4.75")
Weight (incl. Dry Batteries): 115 gms. (4 oz).
Measurement speed: > 40 readings per minute.
Battery Type: 2 x LR03 (AAA), alkaline
d
dry batteries or rechargeable
e
equivalents
