The Elcometer 456 then asks the user to set the counted average
value. Using the up and down arrow softkeys, set the counted
average from 2 - 99 and press the Ok softkey.
This returns the user to the previous screen. Press the Back
softkey to continue setting up the new batch as required before
opening the new batch.
If Statistics are displayed whilst measuring using the counted
average function (CAF) when taking the readings used to calculate
the CAF measurement, the gauge will display the rolling statistical
calculations of the individual readings until all the readings that go
into calculating the CAF measurement are taken. At this point the
statistics then display the values of the stored CAF measurements.
IMO PSPC: If you are inspecting coating thickness according to the
International Maritime Organisations Performance Standard for
Protective Coating, selecting the IMO PSPC batch type and then
subsequently opening the batch, the gauge automatically:
• Asks the user to confirm the NDFT (nominal dry film thickness)
value
• Sets the statistics to display the relevant IMO PSPC values
• Identifies the batch as an IMO PSPC batch for further analysis in
the ElcoMaster™ data management software
For more information on the IMO PSPC see page 74.
For more information on ElcoMaster™ see page 35.
Fixed Batch Size (T)
When creating a new batch, by selecting Batch/New Batch and
checking the Fixed Batch Size radio button, users can pre-define the
number of readings that are to be stored into the batch (between 1 and
255) using the up and down arrow softkeys.
Once the batch has been opened and readings are being taken, the
Elcometer 456 will notify the user when the fixed batch size is
complete and ask if another batch is to be opened.
If the user selects No, then the gauge closes the batch and exits
batching - returning the gauge to the Standard (Immediate) mode.
www.elcometer.com
33
