XVx RF 144 Lower edge for xvtr band x (1-9); 0-999 MHz. For frequencies above 999 MHz,
use only the MHz digits (e.g., for 1296 MHz, use 296 MHz). Tap 1 –9 to select
xvtr band.
XVx IF 28 Specify K3 band to use asthe I.F. for transverter band x (1-9). Tap 1 –9 to
select xvtr band. I.F. band selections include 7, 14, 21, 28, and 50 MHz.
XVx PWR L .01 Sets upper limit on power level for XVTR bandx. Tap 1 –9 to select xvtr band.
H x.x (High power level) specifiesa value in watts, and use of the main antenna
jack(s).This should be used with caution, asyou could damage a transverter left
connectedto these antenna jacks accidentally. L x.xx (Low power level) species
a value in milliwatts, which requires the KXV3 option. (If CONFIG:PWR SET
is set to PER-BAND, the K3 will also save the last-used power setting on each
band. This is especially useful for transverter bands.)
XVx OFS 0.00 Offset (–9.99 to +9.99 kHz) for transverter band x (1-9). Tap 1 –9 to select
xvtr band. Compensates for oscillator/multiplier chain errors.
XVx ADR TRNx Physical decode address (1 to 9) assigned to transverter bandx (1-9). Tap 1 –9
to select xvtr band. Applies to attached Elecraft XV-series transverters and
Elecraft KRC2, which are controlled via the Elecraft “AUXBUS” line. Note:
Decode address range may vary dependingon the type of attached device.
For band switching of other transverter types, see pg. 19 and CONFIG:KIO3.
