56
RX EQ
+0 dB,
each
band
Receiver audio graphic equalizer. VFO A is used as an 8-band bar graph, showing
boost or cut (- 16 dB to +16 dB in 1 dB increments) for each AF band.
The 8 bands are 0.05, 0.1, 0.2, 0.4, 0.8, 1.6, 2.4 and 3.2 kHz. Tap 1 -8 to select an AF
band. VFO A selects boost/cut. Tap CLR to reset all bands to +0 dB.
CW RX EQ is separate from RX EQ for voice modes.
RX EQ is not applicable to DATA modes.
TX EQ
+0 dB,
each
band
Transmit audio graphic equalizer (voice modes only). Functions the same as RX EQ,
above. TX EQ can be adjusted during transmit.
SSB TX EQ is separate from TX EQ for other voice modes. Not applicable to
CW or DATA modes.
VOX GN
0
Adjusts the sensitivity of the VOX to match your mic and voice.
ANTIVOX
0
Adjusts immunity of the VOX circuit to false triggering by speaker audio.
