13-3
CONTROL SYSTEM
Revision Y05-01Service Manual - DNG Series
13.1.4 Main PCB Controller
Water Pump
Humidity
To Room Thermistor
To In Thermistor
To Out Thermistor
To MIU
Buzzer Enabled Jumper
To RS485
Model Plug
Clock
IR Enabled Jumper
To DIN Plug Cable
for display box
To RC-W
Ionizer Connection Plugs
Indoor Fan
Indoor Fan capacitor
Level
