30 Installation Manual
1. Use the wall-mounted bracket as a template and drill holes in the
wall, 10mm in diameter and 80mm deep.
Fix the wall-mounted bracket on the wall using the expansion bolts in
the accessories bag.
2. Carry the auto-transformer by holding the heatsink on two sides and
place the equipment on the mounting bracket.
3. Take a picture within the PowerTools app.
CAUTION: The auto-transformer is small in size, but very
heavy. It is recommended that two people carry it during
installation.
L’auto-transformateur est de petite taille, mais très lourd. Il
est recommandé que deux personnes le portent pendant
l’installation.
Mounting System / Auto-Transformer
