ElectrIQ PowerPod 2 - Technical Specifications (AC-Coupled); AC-Coupled Inverter Output Specifications

84 Installation Manual
Appendix / Technical Specifications (AC)
4.3. TECHNICAL SPECIFICATIONS (AC-COUPLED)
Product Model
PP2-
AC-10/15/20-9600
PP2-
AC-10/15/20-8600
PP2-
AC-10/15/20-7600
PP2-
AC-10/15/20-7000
PP2-
AC-10/15/20-6000
PP2-
AC-10/15/20-5000
Configuration 4/6/8 Batteries in Series
AC INPUT 1 / GRIDTIE Per UL 1741SA
Utility Compatibility Per UL 1741SA
AC OUTPUT / GRID
Rated AC Power Output
(To Grid, From Battery)
75% DOD @ 25°C
5000/7500/9600 VA 5000/7500/8600 VA 5000/7500/7600 VA 5000/7000/7000 VA 5000/6000/6000 VA 5000/5000/5000 VA
Rated AC Power Output
(To Grid, From Battery)
75% DOD @ 45°C
5000/7500/9600 VA 5000/7500/8600 VA 5000/7500/7600 VA 5000/7000/7000 VA 5000/6000/6000 VA 5000/5000/5000 VA
AC Grid Voltage L-L: 211 to 264V, 1Ø
AC Frequency 60Hz 59.3 to 60.5Hz ± 0.05Hz
Maximum Continuous
Output Current
0 to 40 A
(@240 V)
0 to 35.8 A
(@240 V)
0 to 31.7 A
(@240 V)
0 to 29.2 A
(@240 V)
0 to 25 A
(@240 V)
0 to 20.8 A
(@240 V)
AC Circuit Breaker (grid) No
Ground-Fault Isolation
Detection
Integrated Detection Included
Charge Battery from AC Yes
THD (current) < 5 %
Operating (Standy) Power
Consumption
<40 W
Operation Temperature
Range
-20 to 55°C (power derated above 40°C)
Operation Humidity 10% to 90% Non-condensing
Thermal Management Forced convection
Noise Level, Maximum < 45 dBA
Output (AC) / BACKUP
LOAD
AC Backup Power Output
From Battery (DOD 95%)
4500/6750/9000 VA 4500/6750/8600 VA 4500/6750/7600 VA 4500/6750/7000 VA 4500/6000/6000 VA 4500/5000/5000 VA
Maximum Overload 60
s @25°C From Battery
(DOD 95%)
5400/8100/10,800
VA
5400/8100/10,320
VA
5400/8100/9120 VA 5400/8100/8400 VA 5400/7200/7200 VA 5400/6000/6000 VA
AC Backup Power Output
From Battery (SOC 60 to
100%)
5350/7900/9600 VA 5350/7900/8600 VA 5350/7600/7600 VA 5350/7000/7000 VA 5350/6000/6000 VA 5000/5000/5000 VA
Maximum Overload 60 s
@25°C From Battery (SOC
60 to 100%)
6400/9500/11,520
VA
6400/9500/11,320
VA
6400/9120/9120 VA 6400/8400/8400 VA 6400/7200/7200 VA 6000/6000/6000 VA
AC Backup Output Voltage 120/240 VAC
AC Frequency 60Hz
Ground-Fault Isolation
Detection
Integrated Detection Included
AC Circuit Breaker
(inverter)
No
AC Circuit Breaker (inverter
bypass, grid connect)
No
THD (voltage) < 3 %
Power Factor
> 99%
Automatic Switchover
Time
< 1sec
