60 Installation Manual
Inverter / Grid
Inverter from grid connections
Model Number Grid Wire Size Rated for (A)
PP2-AC or DC-5000-10/15/20 35A
PP2-AC or DC-6000-10/15/20 40A
PP2-AC or DC-7000-10/15/20 45A
PP2-AC or DC-7600-10/15/20 50A
PP2-AC or DC-8600-10/15/20 50A
PP2-AC or DC-9600-10/15/20 50A
1. Route the grid cables through the port closest to the grid connectors
and connect to the "GRID" N, L1 and L2 connectors.
