Electrolux T5350 - Gas Pressure and Adjustment Table

Service Manual
45
9.7 Table of pressure and adjustment
Liquied petro-
leum gases
Gas category Inlet pressure
(mbar)
Injector pres-
sure (mbar)
Injector size (⌀
mm)
Air reducing
plate (mm)
Label number May be avail-
able in follow-
ing countries
Butane mixture
/
Propane
mixture
3+ 28-30 /
37
No regulation 2.30 No 490375643 BE, CH, CY,
CZ, ES, FR,
GB, GR, IE, IT,
LT, LU, LV, PT,
SK, SI
Butane 3B/P 30, 37, 50 28 2.30 No 490375644 BE, CY, DK,
EE, FI, FR,
GB, HU, IT, LT,
NL, NO, SE,
SI, SK, RO,
HR, TR, BG,
IS, LU, MT, PL,
AT, CH, DE,
SK
Propane 3P 30, 37, 50 28 2.40 No 490375645 FI, NL, RO,
BE, CH, CZ,
IE, IT, ES, FR,
GR, GB, HR,
LT, NL, PL, PT,
SI, SK, AT, CH,
DE, NL, LU,
SK
Natural gas Gas category Inlet pressure
(mbar)
Injector pres-
sure (mbar)
Injector size (⌀
mm)
Air reducing
plate (mm)
Label number May be avail-
able in follow-
ing countries
2H, 2E 20 8 4.00 No Default AT, BG, CZ,
DK, EE, FI,
GR, HR, HU,
IS, IE, IT, LV,
LT, NO, PT,
RO, SK, SI,
ES, SE, CH,
TR, GB, DE,
PL, LU
2E+ 20 / 25 No regulation 3.30 No 490375641 BE, FR
2LL, 2L 20, 25 12 4.00 No 490375642 NL, DE
