Electrolux T5350 - Pulley Replacement

Service Manual
33
7.6 Replacement of pulley
On machines with reversing
Disconnect the power to the machine.
Demount the rear panel.
Loosen the belt tensioner (B).
Loosen both of the belts (C).
Remove the split pin and the three spring washers (D). Pull off the pulley and mount the new pulley.
Remount the three spring washers and the split pin.
fig.7898
Fasten the belts and make sure the belts are in position. Mount the belt tensioner.
Remount the rear panel.
