Electrolux T5350 - Machine Specifications; Machine Connections

Service Manual
7
2.2 Technical data
Weight, net kg 177
Weight, net, Steam kg 184
Drum volume litres 349
Drum diameter
mm
760
Drum depth
mm
770
Drum speed, medium load
rpm
45
Rated capacity, filling factor 1:18 (Max. load) kg 19.4
Rated capacity, filling factor 1:22 (Recommended load) kg 15.5
Heating: Electricity kW 13.5
kW 18
Heating: Gas kW 21
Heating: Steam at 800 kPa kW 25
Steam pressure kPa 100–1000
Electric heating, 13.5 kW
Maximum air flow
m
3
/h 1000
Electric heating, 18 kW
Maximum air flow
m
3
/h 1000
Gas heating
Maximum air flow
m
3
/h 1000
Steam heating
Maximum air flow
m
3
/h 1000
Maximum static back pressure, Electric 13.5 kW Pa 520
Maximum static back pressure, Electric 18 kW Pa 270
Maximum static back pressure, Gas Pa 270
Maximum static back pressure, Steam Pa 270
A-weighted emission sound pressure level at working stations dB(A) 70
2.3 Connections
Air outlet
⌀ mm
200
Gas connection 1/2” ISO 7/1–R1/2
Steam inlet/outlet ISO 7/1–R1
