Service Manual
5 Sensors and overheating thermostats
5.1 Inlet air
5.1.1 Overheating thermostat
Description
The inlet overheating thermostat is placed on the heating module on the back of the machine.
The inlet overheating thermostat opens in the event of overheating and shuts off the machine.
Resetting
Disconnect the power to the machine. Gas heated machine: Shut off the manual gas valve.
Demount the rear panel.
Press the reset button (A) on the overheating thermostat.
Note!
Resetting must not be done before the cause for overheating is verified and resolved.
fig.W00252
Remount the rear panel.
Replacement of overheating thermostat
Disconnect the power to the machine. Gas heated machine: Shut off the manual gas valve.
Demount the rear panel.
Disconnect the overheating thermostat and remove it. Connect the new overheating thermostat.
El and Gas heated machine.
Remount the rear panel.
