73Maintenance
4.2 Settings
4.2.1 Power supply Dip-switch
In this series there are three power supplies (2.5KW or 3KW).
On the power supplies must set the operating mode (analog, digital), using the dip-
switch SW1, and the address, using the dip-switch SW2.
SW1 SW2
Switch1 Switch2 Switch3 Switch4 Switch1 Switch2 Switch3 Switch4
Power
supply N.1
OFF OFF OFF OFF ON OFF OFF OFF
Power
supply N.2
OFF OFF OFF OFF OFF ON OFF OFF
Power
supply N.3
OFF OFF OFF OFF ON ON OFF OFF
Dip-switch setting parameters
