connect with an analog sensor.
8.4 Ethernet
The Ethernet is provided on the top of the control box. Please refer to the figure below.
The Ethernet interface can be applied to the following applications:
• Remote access and control
The electrical specifications are shown below.
Parameter Min Type Max Unit
Communication speed 10 - 100 Mb/s
8.5 Mains Connection
The mains cable of the control box has a standard rectangular heavy-load plug at the end.
Connect the local dedicated mains socket or cable to the rectangular heavy-load plug.
