17
SECTION 1: INTRODUCTION
1.2 Device Description
Figure 10: Battery Charging Power Supply and AC Power Cord for Battery Charging
The Macroduct Advanced Sweat Collection System includes a universal
input battery charging power supply and AC power cord (120 V cord
shown).
Figure 11: EasyDuct Needle with 1 cc Syringe
The syringe and EasyDuct needle are used to harvest a sweat sample.
The EasyDuct needle is specially designed for easy insertion into the
collector tubing.
Figure 12: Sweat Dispenser
The sweat dispenser is an optional tool used to harvest and store a
sweat sample in the small sealable containers. The sweat dispenser uses
a reduced-end blunt needle for easy insertion into the collector tubing.
Figure 13: USB Cable
The USB cable is a 6-foot long USB A Male to USB Micro B Male cable
used to interface the Macroduct Advanced Model 3710 to a computer
USB port.
Figure 14: Electrode Cleaning Pads
The electrode cleaning pads are packaged in a pack of 10 and are used to
clean and buff the electrodes. They are a mild abrasive pad, which
provide gentle, yet thorough cleaning of the electrodes. The pads are
sized to easily fit within the electrodes and can be used with a fingertip.
