APPENDIX C
Specifications
Table 11 – General Specifications, Macroduct Advanced Model 3710
Category Characteristics
Display/Backlight/Touchscreen
Screen Type: Color TFT-LCD (Thin-Film-Transistor Liquid-Crystal Display)
Screen Size: 5 inch Wide –VGA
Backlight: White LED
Touchscreen: Projected Capacitive (PCAP)
Electrical – Power
Rechargeable battery consisting of lithium-ion cells
Replaceable only by qualified service personnel
Electrical – Back-up
Lithium coin cell for the real-time clock
Replaceable only by qualified service personnel
Iontophoresis Current (nominal) 1.5 mA (automatic)
Iontophoresis Time and Current
Control
Current profile-controlled, approximately 20 second rise time,
approximately 5 second fall time.
Operating Temperature
Operating Humidity
Operating Atmospheric Pressure
15 °C to 30 °C (59 °F to 86 °F)
≤ 85%, non-condensing
≥ 79.5 kPa (2000 m)
Storage Temperature 2 °C to 40 °C (36 °F to 104 °F)
Transportation Temperature -10 °C to 50 °C (14 °F to 122 °F)
Audible Indicator Magnetic Buzzer, 2.4 KHz (typical)
Electrode Cable Assembly
Elliptically shaped electrodes to fit elliptical Pilogel discs
Detect pin for detecting the presence of Pilogel discs
Electrode Connection 6-pin push-pull locking medical connector
Straps Polyurethane straps are non-latex and non-allergenic
USB Connection USB Micro B Connector
Charge Connection Device, DC receptacle, center positive
Power On Indicator Green LED (power switch)
Battery Charging Indicator Blinking Amber LED (power switch), graphical battery charge icon
Battery Charged Indicator Solid Amber LED (power switch), graphical battery charge icon
Device Size (Length x Height x Depth) 17.1 cm x 12.7 cm x 4.4 cm
(6.7 in x 5 in x 1.7 in)
Device Weight 0.6 kg (1.4 lbs)
Carrying Case
(Length x Height x Depth)
34.3 cm x 24.1 cm x 11.4 cm
(13.5 in x 9.5 in x 4.5 in)
Carrying Case Weight
(Including device and accessories)
2.3 kg (5 lbs)
