Faulty operating and switch elements
32
SM/Transsonic_LC/1104/D © Elma GmbH & Co KG
Illustration 8.7.2. Clamped-in capillary probe secured with silicone
red dotted line: cut silicone here to remove the probe
Illustration 8.7.3. Pull off the foil around the control thermostat
Fastening screws for control thermostat
A
