Remote control reception
Point the transmission unit of the remote control at the sensor unit located on the front of
the camera main unit, press the operation button for the intended operation, and operate
the camera main unit accordingly.
Receivable Range
Distance: Within approx. 7m from the front face of the remote control sensor unit.
Angle: Within 30º up, down, left, and right from the remote control sensor unit.
• The receivable range may be shortened or narrowed and the laser beam from the
remote control may not be sensed depending on the surrounding circumstances
(e.g., sunlight, position adjacent to inverter fluorescent lamp). In this case, relocate
the receiving side or shield the sun light or fluorescent lamp.
