• Before connecting the main unit to other devices, be sure to turn off the power for all
of the devices.
•
When copying B&W characters or documents etc., use TEXT1 to 3 from the OSD
(Camera image) as the image mode.
A better image may be pr
oduced by selecting Graphics1 mode with DLP projector.
• When connected to a DLP projector, select the image mode according to the
displayed image as both text and photos can be beautifully reproduced by switching
to Graphics2 mode.
n
Setting the main unit
Set the main unit as shown in the figure above. Then connect it to a projector or a PC
monitor, and turn on the power for the main unit.
n
Adjusting the size
Place an object on the stage, and then adjust the zoom dial on the main unit or the zoom
buttons [
/
] on the remote control so that the part you want to shoot fits the screen
size.
P.49
n
Adjusting the focus
Press the [AF] button on the main unit or on the remote control to focus the camera on the
object.
P.50
n
Adjusting the brightness
Press the [BRIGHTNESS
]/[BRIGHTNESS ] buttons on the operating panel or on
the remote control to adjust the image brightness.
P.53
n
Turning the illumination lamp ON/OFF
Move the illumination lamp switch on the main unit to the left/right to turn it ON/OFF.
OPERATION PROCEDURE
4
