Elmo L-1EX - Page 46

46
OPERATION
PROCEDURE
English
4
Horizontally slide the microscope
attachment and the lens for the main
unit together.
5
Slide in from the side and adjust
the lens for the main unit to the top
surface of the microscope attachment.
N o t e
• The microscope attachment can be used when the eyepiece is 20 to 28 mm. When
using an eyepiece of a different size, shoot without using the microscope attachment.
