36 Display Operation Manual BC2000 and JC2000 Controller ~ Doc. No. 2055882, Issue 5.1, June 2014
Table 5 - Parameter Ranges and Default Settings (Profile A01, 48V Systems)
Parameter Description
Default
Setting
Value Range
System
Float V
The voltage sustained by the rectifiers to
maintain battery charge
54 V 43 – 56 V
Fallback State Fallback state can be enabled or disabled Disabled
Disabled /
Enabled
Fallback V
The voltage to which the rectifiers revert in
the event of a controller failure
50 V 43 – 56 V
Rect I Limit
State
Enables rectifier current limit feature Disabled
Disabled /
Enabled
Rect I Limit
The maximum amount of current that each
installed rectifier outputs
220 A 5 – 220 A
Batt I Limit
State
Enables battery recharge current limit feature
(a battery shunt is required)
Disabled
Disabled /
Enabled
Batt I Limit
The maximum amount of current that the
controller allows to flow into the battery
during recharge (a battery shunt is required)
600A 5 – 600 A
Temp. Unit Select either degrees Celsius or Fahrenheit Celsius
Celsius /
Fahrenheit
Type Indicates 48 V or 24 V system 48 V 48 V / 24 V
Date
Current date. Format depends on “Date
Format” parameter (below).
[Current]
[Depends on
date format]
Time
Current time. Format depends on “Time
Format” parameter (below).
[Current]
[Depends on
time format]
Date Format
Date format can be Month/Day/Year
(MM/DD/YYYY) or Day/Month/Year
(DD/MM/YYYY)
MM/DD/YYYY
MM/DD/YYYY
or
DD/MM/YYYY
Time Format 12- or 24-Hour Clock 24 Hour
12 Hour /
24 Hour
Alarming
History
System history log containing the alarm
events
HV Shutdown
The controller shuts down the rectifiers if
plant voltage exceeds this value
58 V 55 – 60 V
High Voltage
The controller issues a High Voltage Alarm if
the plant voltage exceeds this value
57 V 56.5 – 60 V
Batt Dischrg
The controller issues a Battery-On-Discharge
alarm if the plant voltage falls below this
value
48 V 43 – 54 V
Low Voltage
The controller issues a Low Voltage
Disconnect Warning if the plant voltage falls
below this value
44 V 42 – 54 V
Comm Fail
Enables an alarm to indicate if any rectifier
either stops communicating, or is removed
from the shelf
Disabled
Disabled /
Enabled
