Display Operation Manual BC2000 and JC2000 Controller ~ Doc. No. 2055882, Issue 5.1, June 2014 37
Parameter Description
Default
Setting
Value Range
Comm as ACF
This feature associates the loss of rectifier
communication with an AC failure alarm.
Disabled
Disabled /
Enabled
I Share
A minor alarm is triggered if the output
current of any rectifier exceeds current
sharing tolerances
Enabled
Disabled /
Enabled
Redundancy
A minor alarm is triggered if the number of
installed rectifiers does not support N+1
redundancy
Disabled
Disabled /
Enabled
Audible
Determines which alarm conditions trigger
the audible alarm
Disabled
Disabled
Major Alarms
Minor Alarms
Major+Minor
Any Alarm
Modules
LVDs section (if available)
LVD Contactor
State
Opens and closes the LVD contactor (if
installed)
Closed
Closed
Opened
Disconnect V
The LVD disconnect contactor opens if the
plant voltage falls below this value
42 V 40 – 49 V
Reconnect V
The LVD disconnect contactor closes if the
plant voltage reaches this value
50 V 43 – 57 V
Recon Delay
The amount of time to delay after reaching
the LVD reconnect voltage value before
closing the contactor
00:00:20
(HH:MM:SS)
Max 00:03:59
(239 sec)
Ringers section (if available)
AC Voltage Ringer AC output voltage 86 V 70 – 100 V
DC Voltage
DC voltage value at which the ringer RMS
value is offset. It should be equal to the float
voltage.
54 V 0 – 55 V
Frequency Ringer frequency 20 Hz 17 – 50 Hz
Select
Ring generator priority: None (disabled),
Ringer A (main), or Ringer B (backup)
Ringer A (Main)
None
Ringer A
Ringer B
PM section
PM# Displays PM model, status and serial number Read only
Probe (1–8) Input type of input probe Disabled Read only
Status Status code of PM device
Setup
Probe (1–8)
Sets the behavior of the PM ports.
If an Eltek temp probe is installed, the probe
port is automatically set to “T Probe”
Disabled
Disabled
T Probe
Aux N.O.
Aux N.C.
Dist N.O.
Dist N.C.
