5 - DESCRIPTION OF THE LEDS AND BUTTONS ON THE CARD
Buttons in the circuit
Abbreviation Description
AP/CH Controls opening and closing the gate
P2 Press to enter travel programming
P3 Press to enter radio controls programming or deletion
Preliminary check
After powering up the control panel the DL6 LED comes on with a series of flashes to indicate the version of the firmware. Check the LEDS for diagnosis of
the inputs, STOP, PHOTO and STPA must be on.
ABBREVIATION DESCRIPTION
AC Shows whether there is mains power (lit if there is mains voltage)
STPA
Displays the status of the STPA input (number 19), if not engaged the LED remains lit, if not used then jumper between terminal
COM and STPA
AP/CH Displays the status of the AP/CH input (number 14), if not engaged the LED remains off
APED Displays the status of the APED input (number 15), if not engaged the LED remains off
STOP
Displays the status of the STOP input (number 17), if not engaged the LED remains lit, if not used then jumper between terminal
COM and STOP
Displays the status of the FOTO input (number 18), if not engaged the LED remains lit, if not used then jumper between terminal
COM and FOTO.
ENCM1
Displays the motor 1 encoder input, on steady when the motor is moving at cyclical speed, flashing during slowdown, off with the
motor stopped.
ENCM2
Displays the motor 2 encoder input, on steady when the motor is moving at cyclical speed, flashing during slowdown, off with the
motor stopped.
DL6 Displays the programming status of the travel and of the radio control learning
