48 Chapter 3
5. Remove the two screws securing the ODD bracket and remove the ODD bracket from the optical disk drive
module.
6. Remove the ODD bezel by rotating the top edge downward and pulling it clear of the module.
Step Size Quantity Screw Type
ODD Bracket M2*3 2
