eMachines E627 - Removing the LCD Module

Chapter 3 57
Removing the LCD Module
1. See “Removing the Keyboard” on page 56.
2. Turn the computer over. Remove the two securing screws from the bottom of the chassis.
3. Remove the Antenna Cables from the cable channel as shown. Ensure that the cables are free from all cable
clips.
Step Size Quantity Screw Type
LCD Module M2.5*8 2
