eMachines E627 - Removing the Power Board

Chapter 3 65
Removing the Power Board
1. See “Removing the Upper Cover” on page 61.
2. Locate the Power Board on the Upper Cover as shown.
3. Remove the two screws securing the Power Board to the Upper Cover.
4. Lift the Power Board clear of the Upper Cover as shown.
Step Size Quantity Screw Type
Power Board M2*3 2
