eMachines E627 - Removing the LCD Panel

82 Chapter 3
Removing the LCD Panel
1. See “Removing the Camera Module” on page 81.
2. Remove the two securing screws from the LCD Panel.
3. Remove the adhesive strip holding the cables in place.
4. Remove the Camera cable cluster from the LCD Module as shown.
Step Size Quantity Screw Type
LCD Panel M2.5*6 2
