eMachines E627 - Removing the Left Speaker Module

66 Chapter 3
Removing the Left Speaker Module
1. See “Removing the Upper Cover” on page 61.
2. Locate the Left Speaker Module on the Upper Cover as shown.
3. Remove the adhesive tape from the Speaker cable.
4. Remove the Speaker cable from the cable channel. Ensure that the cable is free from all cable clips.
