eMachines E627 - Removing the Thermal Module

74 Chapter 3
Removing the Thermal Module
1. See “Removing the Lower Covers” on page 46.
2. Turn the Mainboard over to access the Thermal Module.
3. Remove the four securing screws (in reverse numerical order from screw 4 to screw 1) from the Thermal
Module.
Step Size Quantity Screw Type
Thermal Module M2.5*6 4
1
2
3
4
