eMachines E627 - Removing the Upper Cover

Chapter 3 61
Removing the Upper Cover
1. See “Removing the LCD Module” on page 57.
2. Turn the computer over. Remove the eleven screws on the bottom panel.
3. Turn the computer over. Remove the three screw caps at the rear of the Upper Cover as shown.
Step Size Quantity Screw Type
Upper Cover M2.5*8 11
