64 Chapter 3
9. Remove the nine screws on the top panel.
10. Starting at the rear left side of the cover, pry apart the Upper and Lower Covers as shown. Work along the back
edge of the casing to the right as shown, then lift the Upper Cover clear of the Lower Cover.
Step Size Quantity Screw Type
Upper Cover M2.5*8 9
