AIRPLANE
FLIGHT
LIMITATIONS
ANAC APPROVED 2-40
REVISION 5 code 09 Page 1
POWER PLANT
ENGINES
Two General Electric CF34-10E7 or two General Electric
CF34-10E7-B.
OPERATIONAL LIMITS
PARAMETER MIN MAX
N1 - 100%
N2 - 100%
ITT: - -
Ground Start - 740° C
Inflight Start - 875° C
Normal Takeoff and Go Around - 943° C (1) (3)
Maximum Takeoff and Go Around
-
983° C (1) (2)
(3)
Maximum Continuous - 960° C
OIL PRESSURE 25 psi (4) -
OIL TEMPERATURE: - -
Continuous - 155° C
NOTE: 1) Time limited to 5 minutes.
2) Automatically engaged mode in one engine inoperative or
windshear conditions, when the thrust lever is in the TOGA
position.
3) ITT transients above the nominal ITT limits are allowed to
Normal and Maximum takeoff, up to 5.5° C for 2 seconds,
4.4° C for 5 seconds, 3.6° C for 15 seconds and 2.4° C for
30 seconds.
4) During starts with oil temperature below –22° C the
minimum oil pressure is 5 psi, time limited to 2 minutes.
