APPENDIX 1
CONFIGURATION
DEVIATION LIST
AIRPLANE
FLIGHT
MANUAL
AP1-55 ANAC APPROVED
Page 2 code 01 REVISION 12
Copyright © by Embraer. Refer to cover page for details.
AFM
-
1
912
CONFIGURATION DEVIATION LIST
System & 1. 2. Number installed
Sequence ITEM 3. Number required for dispatch
Number 4. Remarks and/or exceptions
55 STABILIZERS
03-05 Vertical Stabilizer
Access Panel Seal
(RH)
4 - May be missing with negligible
penalty in one of the following
conditions:
- Up to two seals may be
partially or totally missing in
any combination, or;
- Up to 25% length of all right-
hand vertical stabilizer seal
(aerodynamic + access panel)
may be missing.
03-06 Horizontal Stabilizer
Access Panel Seal
(Lower Side)
12 10 One or two seals may be
partially or totally missing in any
combination with negligible
penalty.
03-07 Vertical Tail Access
Doors (323KR/LR)
2 0 One or both may be missing
with no penalty. Cover the
cavity with speed tape.
14-01 Horizontal Stabilizer
Aerodynamic Seal
(Upper Side)
8 7 One seal may be partially or
totally missing with negligible
penalty.
14-02 Horizontal Stabilizer
Aerodynamic Seal
(Lower Side)
12 10 One or two seals may be
partially or totally missing in any
combination with negligible
penalty.
24-01 Elevator Root Fairing
Seal
2 0 One or two seals may be
partially or totally missing with
negligible penalty.
