EMBRON Hatteland E Series - Page 122

122
Appendix
IND100077-218
BIOS Default Settings Overview
Internal USB 3.0 -1
[Disabled] *
[Enabled]
Internal USB 3.0 -2
[Disabled] *
[Enabled]
USB port 4 on Terminal (top)
[Disabled] *
[Enabled]
USB port 3 on Terminal
[Disabled] *
[Enabled]
USB port 2 on Terminal
[Disabled] *
[Enabled]
USB port 1 on Terminal (bottom)
[Disabled] *
[Enabled]
Internal USB 2.0 -1
[Disabled] *
[Enabled]
Internal USB 2.0 -2
[Disabled] *
[Enabled]
Reset Mode
Internal USB 3.0 -1
[Disabled] *
[Enabled]
Internal USB 3.0 -2
[Disabled] *
[Enabled]
USB port 4 on Terminal (top)
[Disabled] *
[Enabled]
USB port 3 on Terminal
[Disabled] *
[Enabled]
USB port 2 on Terminal
[Disabled] *
[Enabled]
USB port 1 on Terminal (bottom)
[Disabled] *
[Enabled]
Internal USB 2.0 -1
[Disabled] *
[Enabled]
Internal USB 2.0 -2
[Disabled] *
[Enabled]
Panel power
panel power control
[Disabled]
[Enabled] *
panel supply voltage
[3.3V]
[5V] *
RTC Battery Alarm Voltage
RTC Battery Alarm Voltage
[Disabled] [Disabled]
[2.0V] * [2.0V]
[2.1V] [2.1V]
[2.2V] [2.2V]
[2.3V] [2.3V]
[2.4V] [2.4V] *
[2.5V] [2.5V]
[2.6V] [2.6V]
[2.7V] [2.7V]
[2.8V] [2.8V]
[2.9V] [2.9V]
[3.0V] [3.0V]
SCOM Bus Settings
SCOM Bus Status
Working
Type No.
N/A
Serial No.
N/A
FW Version
FW100005-TA09
Keypad
No Keypad
IO Card
No IO Card
Buzzer Off
[Disabled]
[Enabled] *
Power Mode
[Always On] *
[Power Button Only]
[Previous State]
External RTC Configuration
Auto Sync RTC
[Disabled] *
[Enabled]
BIOS Setup Values
Doc No.
Board: APOLLOL
BIOS: APOLLOL-W1M-190718
1. Setup pages and values
Items BIOS default setting comment
Main>
BIOS Information
BIOS Version APOLLOL-W1M-190718 APOLLOL-W1MA190718
Memory Information
Total Memory
xxxx BM
Memory Memory
xxxx MHz
System Date [xx xx/xx/xxxx]
System Time [xx:xx:xx]
Advanced>
Trusted Computing
TPM20 Device Found
Vendor: IFX
Firmware Version: 7.62
VGA Palette Snoop
[Disable]
[Enable] * Sub menu is visible only when this item is Enabled
Active PCR banks
SHA-1,SHA256
Available PCR banks
SHA-1,SHA256
Pending operation
[None] *
[TPM Clear]
Platform Hierarchy
[Disable]
[Enabled] *
Storage Hierarchy
[Disable]
[Enabled] *
Endorsement Hierarchy
[Disable]
[Enabled] *
TPM2.0 UEFI Spec Version
[TCG_1_2]
[TCG_2] *
Physical Presence Spec Version
[1.2]
[1.3] *
TPM20 InterfaceType
[CRB]
Device Select
[TPM 1.2]
[TPM 2.0]
[Auto] *
ACPI Settings
Enable Hibernation
[Disabled]
[Enabled]*
ACPI Sleep State
[Suspend Disabled]
[S3 (Suspend to RAM)]*
LVDS (eDP/DP) Configuration
LVDS (eDP/DP) Controller
[Disabled]
[Enabled]* Sub menu is visible only when this item is Enabled
LVDS Protocol
[18bit, Single Channel]
[18bit, Dual Channel]
[24bit(VESA), Single Channel]
[24bit(VESA), Dual Channel] *
[24bit(JEIDA), Single Channel]
[24bit(JEIDA), Dual Channel]
Panel Type
[800 x 480]
[1024 x 768]
[1280 x 1024]
[1366 x 678]
[1440 x 900]
[1600 x 900]
[1920 x 1080] *
Power Configuration
Power Mode
APOLLOLW1MA
16T30, 21T30, 24T30, 27T30
