Appendix
IND100077-218
BIOS Default Settings Overview
F81964 Super IO Configuration
Super IO Chip F81964
Serial Port 1 Configuration
Serial Port
[Disabled]
[Enabled] *
Device Settings
IO=3F8h; IRQ=4
Change Settings
[Auto] *
[IO=2F8h; IRQ=3]
[IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12]
[IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12]
[IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12]
[IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12]
Serial Port 2 Configuration
Serial Port
[Disabled]
[Enabled] *
Device Settings
IO=2F8h; IRQ=3
Change Settings
[Auto] *
[IO=3F8h; IRQ=4]
[IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12]
[IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12]
[IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12]
[IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12]
Serial Port 3 Configuration
Serial Port
[Disabled]
[Enabled] *
Device Settings
IO=3E8h; IRQ=5
Change Settings
[Auto] *
IO=3E8h; IRQ=5
IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12
IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12
IO=2F0h; IRQ=3,4,5,6,7,9,10,11,12
IO=2E0h; IRQ=3,4,5,6,7,9,10,11,12
Serial Port 4 Configuration
Serial Port
[Disabled]
[Enabled] *
Device Settings
IO=2E8h; IRQ=7
Change Settings
[Auto] *
IO=2E8h; IRQ=7
IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12
IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12
IO=2F0h; IRQ=3,4,5,6,7,9,10,11,12
IO=2E0h; IRQ=3,4,5,6,7,9,10,11,12
Multi Function
[RS-232] *
[RS-485]
[RS-422]
Terminal
[off] * This menu is only configuable when set RS485 or 422
[on]
RS485 RTS# Auto Flow Control
[Disabled] * This menu is only visible when set RS485
[Enabled]
H/W Monitor
PC Health Status
Smart Fan 1 Function
[Disabled] *
50 C
60 C
70 C
80 C
90 C
Smart Fan 2 Function
[Disabled] *
50 C
60 C
70 C
80 C
90 C
ACPI Shutdown Temperature
[Disabled] *
