BIOS Default Settings Overview
SDIO Access Mode
[PIO]
Mass Storage Devices:
--
Sdio Device 1 Details:
--
Bus 0 Dev 1c Func 0
USB Configuration
USB Device:
USD Module Version 17
USB Controllers: 1 XHCI
USB Devices: 1 Keyboard, 1Mouse
Legacy USB Support
[Enabled] *
[Disabled]
[Auto]
EHCI Hand-off
[Enabled] *
[Disabled]
USB Mass Storage Driver Support
[Enabled] *
[Disabled]
USDB hardware delays and time-outs:
USB transfer time-out
[1 sec]
[5 sec]
[10 sec]
[20 sec] *
Device reset time-out
[10 sec]
[20 sec] *
[30 sec]
[40 sec]
Device power-up delay
[Auto]*
[Manual] Sub menu is visible only when this item is Manual
Device power-up delay in seconds
[5] *
[1..40]
Chipset>
Uncore Configuration
IPU PCI Device Configuration:
USD Module Version 17
USB Controllers: 1 XHCI
USB Devices: 1 Keyboard, 1Mouse
IPU Enable/Disable
[Disabled] *
[Enabled] Sub menu is visible only when this item is Enabled
SA IPU ACPI mode
[Disabled]
[IGFX Child] *
[ACPI]
Rear camera
[Disabled] *
[IMX214]
[IMX135]
Front Camera
[Disabled]
[0V2740] *
Rotation
[0] *
[90]
[180]
[270]
South Cluster Configuration
HD-Audio Configuration
HD-Audio Support
[Enabled] *
Disabled
LPSS Configuration
Low power sub system
LPSS I2C #5 Support (D23:F0)
[Disabled] *
[PCI]
[APCI]
LPSS I2C #8 Support (D23:F3)
[Disabled] *
[PCI]
[APCI]
SATA Device
Chipset-SATA Controller Configuration
Chipset SATA
[Enabled] *
Chipset SATA
Disabled
SATA Mode Selection
[AHCI] *
SATA Port 0
xxx
SATA Port 1
xxx
USB Configuration
XHCI Pre-Boot Driver
[Enable]
[Disable] *
XHCI Mode
[Enable] *
[Disable]
USB VBUS
[Off]
[ON] *
USB HSIC1 Support
[Enable]
[Disable] *
USB SSIC1 Support
[Enable]
[Disable] *
USB Port Disable Override
[Disabled] *
[Enabled] Sub menu is visible only when this item is Enabled
USB Port #0
[Disable]
[Enable] *
USB Port #1
[Disable]
[Enable] *
USB Port #2
[Disable]
[Enable] *
USB Port #3
[Disable]
[Enable] *
USB Port #4
[Disable]
[Enable] *
USB Port #5
[Disable]
[Enable] *
USB Port #6
[Disable]
[Enable] *
USB Port #7
[Disable]
[Enable] *
USB 3 Port #0
[Disable]
[Enable] *
USB 3 Port #1
[Disable]
[Enable] *
USB 3 Port #2
[Disable]
[Enable] *
USB 3 Port #3
[Disable]
[Enable] *
USB 3 Port #4
[Disable]
[Enable] *
USB 3 Port #5
[Disable]
[Enable] *
XDCI Support
[Disabled] *
[PCI Mode]
XHCI Disable Compliance Mode
[FALSE] *
[TRUE]
Security>
Setup Administrator Password --
User Password --
Secure Boot
System Mode
User
Secure boot
Not active
Vendor Keys
Active
Attempt Secure Boot
[Disabled] *
Password Description
IF ONLY the administrator's password is set,
then this only limits access to Setup and is only asked for when entering Setup.
IF ONLY the User's password is set, then this is a power on password and must be entered to boot or enter
Setup. In Setup the User will have Administrator rights.
the password length must be in the following range:
Minimum length 3
Maximum length 20
