EMC INDUSTRIAL GROUP LTD Internal Signals
MW61A_IM_ALL_SV6.09d_en 28/47
Q2242 AI2 current high 8142, g2 20.000 mA
This is the high point of the analog signal (when using the current input) within the range 0 to 20 mA
(typically set this variable to 20 mA).
Q2243 AI2 voltage low 8144, g2 0.000 V
This is the low point of the analog signal (when using the voltage input) within the range 0 to 10 V
(typically set this variable to 0 V).
Q2244 AI2 voltage high 8146, g2 10.000 V
This is the high point of the analog signal (when using the voltage input) within the range 0 to 10 V
(typically set this variable to 10 V).
Q2245 AI2 signal type 8148, g2
10
1
This allows correct units and ranging to be applied to the AI2 signal. For example a setting of 1 con-
verts the signal to a weight, a setting of 3 converts the signal to a flowrate.
Q2246 AI2 signal low 8150, g2
11
0 kg,t,g
This is the signal that should correspond with the ‘AI2 current low’ or ‘AI2 voltage low’ point.
Q2247 AI2 signal high 8152, g2
11
1000 kg,t,g
This is the signal that should correspond with the ‘AI2 current high’ or ‘AI2 voltage high point.
Q2248 AI2 current/voltage 8720, g2 mA or V
Displays the remote analog signal as a current or voltage.
Q2249 AI2 signal 8722, g2 kg,t,g
Displays the remote analog signal in engineering units.
local/remote option description
0 default
1
When in local mode, the run input function is disabled. When in remote
mode, the start/stop key functions are disabled.
Internal Signals
Basic Settings
Inputs Internal Signals Outputs
Communications & Display
Information, Resets & Final Calibration
Weight
Basic weight
Q23111 gross weight 8740 kg,t,g
Displays the gross weight.
Q23112 tare weight 8222 0 kg,t,g
Set the tare weight.
Q23113 net weight 8742 kg,t,g
Display of the current net weight (ie gross weight – tare weight).
Q23114
weight (gross or net weight depending on mode)
8744 kg,t,g
Displays the gross or net weight depending on the mode.
Weight zeroing
Q23121 zero range 8212 2.00 %
The maximum range as a percentage of the Weight Capacity over which a zero may be acquired. This
restricts the operation of both an operator initiated zero (pressing the ZERO key) or an automatic zero
when the zero tracking band is enabled.
Q23122
enable tracking zero [0=disable, 1=enable]
8214, g5 0
Enables or disables automatic zero tracking. If enabled, the weight reading is zeroed automatically if
the motion indicator is off, the zero band indicator is on and the amount zeroed (since the last zero
calibration) will stay within the zero range.
Q23123 zero band 8216, g5
12
0.5 divs
Defines the zero band either side of zero. A setting of 0 sets a band of ± ¼ of a division. If set to
0.5kg, the zero band is between -0.5kg and +0.5kg This setting effects the automatic zero tracking if
enabled.
10
0=general, 1=weight, 2=belt speed, 3=flowrate, 4=total, 5=belt loading, 6=length, 7=short length, 8=current, 9=voltage
11
Signal units are determined by units of AI2 signal type
12
Set in divisions of weight, the smallest weight increment as displayed when setting the weight capacity or weight divisions. [0.5 to 12]
