EMC VNX Series Parts Location Guide

Storage processor enclosure (SPE)
EMC VNX7500 Parts Location Guide 11
Table 2 lists the part number label location, part number, description, and whether it is a
FRU or CRU.
Storage processor enclosure (SPE)
The 2U SPE has part numbers visible on both the front and rear.
Front view
Figure 7 shows the front of an 2U SPE.
Figure 7 SPE front view
Table 2 2U SPS part number
Part number label
location (Figure 6
on page 10) Part number Description FRU CRU
078-000-050 DC standby power supply (SPS)
2.2 KW

AC
AC
AC
AC
2
CNS-001723
1

EMC VNX Series Specifications

General

Management Interface	Unisphere
Drive Support	SAS, NL-SAS, Flash (SSD)
RAID Levels	RAID 0, 1, 3, 5, 6
Protocols Supported	Fibre Channel, iSCSI, NFS, CIFS
Data Services	Deduplication, Compression, Snapshots, Replication
Processor	Intel Xeon
Operating System	VNX Operating Environment (block), VNX File Operating Environment (file)
