24 EMC VNX7500 Parts Location Guide
I/O modules
SP
Six types of I/O modules are supported in the SP:
◆ “Four-port 8-Gb/s Fibre Channel (FC) I/O module” on page 25
◆ “Four-port 1-Gb/s copper iSCSI I/O module” on page 28
◆ “Two-port 10-Gb/s optical (w/iSCSI protocol) I/O module” on page 29
◆ “Four-port 6-Gb/s SAS I/O module” on page 30
◆ “Two-port 10-Gb/s Fibre Channel over Ethernet (FCoE) I/O Module” on page 31
◆ “Two-port 10-Gb/s Base-T iSCSI/IP I/O module” on page 34
Data Mover
Seven types of I/O modules are supported in the Data Mover:
◆ “Four-port 8-Gb/s Fibre Channel (FC) I/O module” on page 25
◆ “Two-port 1-Gb/s copper plus two-port 1-Gb/s optical I/O module” on page 26
◆ “Two-port 10-Gb/s Fibre Channel over Ethernet (FCoE) I/O Module” on page 31
◆ “Two-port 10-Gb/s optical I/O module” on page 32
◆ “Four-port 1-Gb/s copper I/O module” on page 33
◆ “Two-port 10-Gb/s Base-T iSCSI/IP I/O module” on page 34
◆ “Two-port 10-Gb/s optical I/O module” on page 35
Table 14 I/O module types for VNX7500
I/O module Part number Ports
Latch handle
label
Latch
handle
label color
Four-port 8-Gb/s FC 303-092-102B Optical 8 Gb Fibre Silver
Four-port 1-Gb/s 303-141-100A Copper 1 GbE iSCSI/TOE Orange
Two-port 10-Gb/s (w/iSCSI) 303-081-105B Optical 10 GbE Orange
Two-port 10-Gb/s FCoE 303-142-100A Optical 10 GbE/FCoE Green
Two-port 10-Gb/s RJ-45
Base-T iSCSI/IP
303-164-104D-01 Copper 10 GbE Base-T Orange
Two-port 1-Gb/s copper
plus two-port 1-Gb/s
optical
303-122-100A or B Copper
plus
optical
1 GbE Brown
Two-port 10-Gb/s 303-081-103B or C Optical 10 GbE iSCSI or
10 GbE v2
Orange
Two-port 10-Gb/s 303-195-100C-01 Optical 10 GbE v3 Orange
Four-port 10/100/1000
Ethernet
303-121-100A Copper 1 GbE Brown
Four-port 6-Gb/s SAS 303-163-100C-01 SAS 6 Gb SAS v1 Black
