30 EMC VNX7500 Parts Location Guide
I/O modules
Four-port 6-Gb/s SAS I/O module
Figure 25 shows the part number label location on the four-port 6-Gb/s SAS I/O module
(labeled 6 Gb SAS v1 on the latch handle).
Figure 25 Example of the four-port 6-Gb/s SAS I/O module
Table 20 shows the part number label location, part number, description, and whether it
is a FRU or CRU.
0123
Part Number (P/N label
VNX-000617
Table 20 Four-port 6-Gb/s SAS I/O Module part numbers
Part number label
location
(Figure 25) Part number Description FRU CRU
303-163-100B Four-port 6-Gb/s SAS 
